Troubleshooting? Or do not know what is going on on with the Q0 Mini 8K Motion Key? You could attempt to manufacturing unit reset it.
How you can manufacturing unit reset the Q0 Mini 8K motion key
1. Open the launcher web site. Hyperlink：https://launcher.keychron.com/
2. Plug the facility cable into your Q0 Mini 8K motion key.
3. Click on the ‘Join‘ button and choose the Q0 Mini 8K.
How you can flash the firmware of the Q0 Mini 8K’s motion key
Mac system:
1. Open the launcher web site. Hyperlink：https://launcher.keychron.com/
2. Plug the facility cable into your Q0 Mini 8K.
3. Click on the ‘Join‘ button and choose the Q0 Mini 8K.
4. Click on ‘Firmware Replace‘ on the left.
5. If you get to the subsequent web page, please click on ‘Subsequent‘ to flash the firmware.
6. Within the present state, unplug the USB cable and let the system disconnect.
7. Whereas the system is disconnected, press and maintain the reset button on the PCB of the Q0 Mini 8K and concurrently join the system to the pc with the USB cable. Let the Q0 Mini 8K enter the state of getting ready to replace the firmware. (Click on to play the video beneath.)
8. Click on the ‘Match Gadget ‘ button beneath, choose the system that begins with “DFU in FS Mode”, and join it.
9. After efficiently matching, click on the ‘Flash Firmware‘ button to start out updating the firmware.
(Don’t disconnect the Q0 Mini 8K from the pc whereas flashing firmware.)
10. Wait some time, ‘Firmware replace efficiently‘ is displayed on the high of the display, Firmware Replace full.
(After finishing the “Firmware Replace”, you have to unplug and replug the USB cable earlier than you need to use your Q0 MIni 8K as typical.)
Home windows system:
1. Open the launcher web site. Hyperlink：https://launcher.keychron.com/
2. Plug the facility cable into your Q0 Mini 8K.
3. Click on the ‘Join‘ button and choose the Q0 Mini 8K.
4. Click on ‘Firmware Replace‘ on the left.
5.Then, Click on the ‘Obtain Toolbox‘ button beneath to obtain and unzip Toolbox.
6. After unzipping Toolbox, right-click the Toolbox icon and click on ‘Run as administrator‘ to open it.
7. Open it and click on on the menu ‘Software’.
8. Click on ‘Set up Drivers‘, proceed to click on ‘Sure’ to start out putting in firmware Drivers, and look forward to the set up.
9. After the set up is full, you may click on ‘Subsequent‘ to start out the method of flashing the firmware.
10. If you get to the subsequent web page, please click on ‘Subsequent‘ to flash firmware, and if you have to re-select the system, please click on Reconnect.
11. Within the present state, unplug the USB cable and let the system disconnect.
12. Whereas the system is disconnected, press and maintain the reset button on the PCB of the Q0 Mini 8K and concurrently join the system to the pc with the USB cable. Let the Q0 Mini 8K enter the state of getting ready to replace the firmware. (Click on to play the video beneath.)
13. Click on the ‘Match Gadget ‘ button beneath, choose the system that begins with “DFU in FS Mode”, and join it.
14. After efficiently matching, click on the ‘Flash Firmware‘ button to start out updating the firmware.
(Don’t disconnect the Q0 Mini 8K from the pc whereas flashing firmware.)
15. Wait some time, ‘Firmware replace efficiently‘ is displayed on the high of the display, Firmware Replace full.
(After finishing the “Firmware Replace”, you have to unplug and replug the USB cable earlier than you need to use your Q0 Mini 8K as typical.)
